V - Belt
V - Belt
Features
- Made from high performance polymers.
- High tenacity polyester cable cords.
- Unique process of heat stretching &, length stabilizing.
- Precision Builtit - no matching required.
- One shot tensioning.
V belts are widely used on high speed and high torque drives on light, heavy industrial and automotive machines. The V belts that are manufactured are incorporated with the latest art of technology and compiling all the IS : International Standards. These belts have exceptional length stability, have a great shock absorbing capacity and drive uniformity. The range of V Belts has different sections namely A, B, C, D and E.
Enquire NowRange
| Section | Nominal Top Width (mm) |
Nominal Thickness (mm) | Angle (Deg.) |
Size Range (inch) | Pitch Length (mm) |
| A | 13.0 | 8.0 | 40 | 16* - 225* | 36 |
| B | 17.0 | 11.0 | 40 | 19* - 598* | 43 |
| C | 22.0 | 14.0 | 40 | 36* - 598* | 56 |
| D | 32.0 | 19.0 | 40 | 95* - 598* | 79 |
| E | 38.0 | 23.0 | 40 | 100* - 598* | 92 |
